Color: Black
Pitch: 2 mm (0.079 in)
Gender: Receptacle (Female)
Unit Weight: 518 mg
Contact Gender: Without Socket Contacts
Current Rating: 3 A
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Voltage Rating: 250 V
Wire Gauge Max: 20 AWG
Wire Gauge Min: 28 AWG
Contact Plating: Tin
Housing Material: Polybutylene Terephthalate (PBT)
Wire Gauge Range: 20 AWG to 28 AWG
Termination Style: Crimp
Flammability Rating: UL 94 V-0
Number of Positions: 8 Position
Insulation Resistance: 100 MOhms
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
