Pitch: 1.27 mm
Height: 5.6 mm
Length: 54.9 mm
Card Type: PCMCIA
Orientation: Right Angle
Unit Weight: 7.700 g
Mating Cycles: 10000
Mounting Type: Reverse
Current Rating: 500 mA
Mounting Style: PCB Mount
Number of Rows: 2 Row
Voltage Rating: 125 VAC
Contact Plating: Gold
Contact Material: Brass
Housing Material: Polybutylene Terephthalate (PBT)
Termination Style: SMD/SMT
Number of Contacts: 68 Contact
Flammability Rating: UL 94 V-0
Insulation Resistance: 1 GOhms
Insertion - Extraction Style: Manual-Push Button Ejector
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 55 C
