Hirose Electric ZE05-8DS-HU/R(A) Plug Housing Receptacle 8pos 0.5 Size 2mm pitch Automotive Interface Connector

Name: Hirose Electric ZE05-8DS-HU/R(A) Plug Housing Receptacle 8pos 0.5 Size 2mm pitch Automotive Interface Connector
Brand: Hirose Electric

ModelZE05-8DS-HU/R(A)

Contact

Quantity

Secure Checkout

Quality Engagement

Easy change and return

Delivery Available

Color: Black

Pitch: 2 mm (0.079 in)

Contact Type: Socket

Current Rating: 2 A

Housing Gender: Plug

Mounting Angle: Straight

Mounting Style: Cable Mount / Free Hanging

Number of Rows: 2 Row

Voltage Rating: 60 VAC, 60 VDC

Wire Gauge Max: 20 AWG

Wire Gauge Min: 22 AWG

Housing Material: Polyamide (PA)

Termination Style: Crimp

Flammability Rating: UL 94 V-0

Number of Positions: 8 Position

Description/Function: Automotive Interface

Insulation Resistance: 100 MOhms

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C
