Power Supply: 220V AC -5% to +10%,Freq: 50Hz±5%
Environment:
-Temperature: -5ºC~40ºC
- Humidity:< 85%
Security:
-Insulation resistance:> 2MΩ
-Leakage: < 3.5mA
Sensitivity: 0.1PC
Measurement Band: 3dB Bandwidth of 10kHz-1000kHz
Lp: 10K,20K,40K,80K
HP: 100K,200K,300K,1000K
Gain Range: -20 dB ∽ +40 dB Fourth Gear
Sampling Accuracy: 12bit
Sample Rate: 10m /Sec.
External Voltage Monitoring: RMS Voltage, 14-Bit a / D Accuracy
Synchronization: Internal and External Optional, External Synchroni
Sync Input Range: 10V~220V
Linearity Error of The Range Stalls: Less Than 5% ± 1PC
