Print Method: Thermal Transfer and Direct Thermal
Dimensions (L x H x W): 506 mm x 398.7 mm x 261 mm (19.92 in x 15.70 in x 10.28 in)
Weight: 23.5 kg (51.81 lbs)
Print specifications:
Print Resolution:
At 203 dpi: 8 dots/mm
At 300 dpi: 11.8 dots/mm
At 600 dpi: 23.6 dots/mm
Print Speed:
At 203 dpi: 50–350 mm/s (2–14 ips)
At 300 dpi: 50–300 mm/s (2–12 ips)
At 600 dpi: 25–150 mm/s (1–6 ips)
Label Roll Maximum Diameter: 212.7 mm (8.375 in)
Label Roll Core: 76 mm (3 in) or 388 mm (1.5 in)
Ribbon roll:
Roll Max. Diameter: 80 mm (3.15 in), approximately 450 m (1,476 ft)
Scan Resolution: 600 dpi
Maximum Scan Width: 108 mm (4.25 in)
Light Source: 660 nm
Maximum Verification Speed:
At 203 dpi & 300 dpi: 250 mm/s (10 ips)
At 600 dpi: 150 mm/s (6 ips)
INTERFACES
Standard:
USB 2.0 Host (x2)
USB 2.0 Device
Ethernet 10/100 Mbps
RS-232, up to 115.2 KB/s
Bluetooth LE (for Print Set MC only)
Static NFC tag (Bluetooth MAC address)
POWER SUPPLY
200 watt rated power supply with PFC
AC Voltage: 100V AC to 240V AC, 50 Hz to 60 Hz
