Display: 4.3-inch large screen LCD display
Test Parameters: Insulation resistance (IR), leakage current (I), volume resistivity (Rv), area resistance (Rs)
Readback Voltage Accuracy: 0.5%±1V
Output Voltage: Programmed:1~1000 V, Step value:1mV
Measurement Range:
Resistance: 1Ω-9.9PΩ,
Leakage current: 2mA~10fA
Ranges: Six different measurement ranges;
auto and manual modes are available in each range
Basic Accuracy: 1%(10M~1G);3% (1G~10G)；5%(10G~100G);10%(100G~1T);20%(≥1T)
Test Speed: 1 meas/sec., 5meas/sec.
Calibration: Open-circuit reset for all ranges
Timing Charger: 0~999.9S
Comparator: 1 set data records, judging over the upper limit ( HI), qualified (IN), and less than the lower limit(LO)
Trigger mode: Internal trigger, manual trigger, external trigger, bus trigger
Interface: RS-232, Handler (PLC)
Result Display: Direct reading, ΔABS, Δ%, θ, sorting result
Max Reading DIgits: 99999 five-digit display
Power supply: 198VAC～240VAC, 47Hz-63Hz, max power 50VA
Size and Weight: 331mm*329mm*80mm (L*W*D), gross weiht:2.5kg
Accessories: HT9330 cable,PB36 connector, HT9800 cable, Power cord, USB
Options: HT0305 test electrode
