Display: 95mm*20mm monochrome LCD
Test Parameters: IR
Basic accuracy: 5%( 0~15A);2% (＞15A)
Output Current: source is programmable within 10A～100A DC
Test Range: 0.01μΩ~600mΩ
Maximum Output Power: 600W
Range: Automatic range
Test Time: 0.1S~999.9S or continuous
Comparator: 3 test-conditions saving, binout with sound and light prompt
Test Result: read-back current, DC-resistance, binout
Interface: RS232/RS485(optional), I/O interface
Protocol: MODBUS
Power Supply: Voltage:198V-240V AC Frequency:47Hz-63Hz
Power Maximum: 650VA
Dimensions: 344mm*280mm*99mm (L*W*H）
Weight: 5.2kg
