HORIBA DS-71A-S LAQUA EC/Res/TDS/Sal/Temp colour touchscreen LCD bench meter

-Function:

Printer connectivity (GLP / GMP)

Temperature compensation (Auto / manual)

AutoHold function

Security (pass word)

-Conductivity:

Measurement method: 2 AC bipolar method

Measurement range(Display range):

Cell constant 100 m-1: 0.000 mS / m ~ 19.99 S / m

Cell constant 10 m-1: 0.0 μS / m ~ 1.999 S / m

Cell constant 1000m-1: 0.00 mS / m ~ 199.9 S / m

Resolution: 0.05% of full scale

Repeatability: ± 0.5% ± 1 digit

Change unit

Distilled water temperature conversion

-Salinity:

Measurement method: Conversion from conductivity value

Measurement range(Display range): 0.00 ~ 80.00 PPT (0.000% ~ 8.000%)

Resolution: 0.01 PPT (0.001%)

Salt concentration calibration

-Resistivity:

Measurement method: Conversion from conductivity value

Measurement range(Display range):

Cell constant 100 m-1: 0.00 Ω · m ~ 199.9 kΩ · m

Cell constant 10 m-1: 0.0 Ω · m ~ 1.999 MΩ · m

Cell constant 1000 m-1: 0.000 Ω · m ~ 19.99 kΩ · m

Resolution: 0.05% FS

Repeatability: ± 0.5% FS ± 1 digit

-TDS:

Measurement method: Conversion from conductivity value

Measurement range(Display range): 0.01 mg / L ~ 100 g / L

Resolution: 0.01 mg / L

-Temperature:

Measurement range: 0.0 ~ 100.0 ℃ (-30.0 ~ 130.0 ℃)

Resolution: 0.1 ℃

Repeatability: ± 0.1 ℃ ± 1 digit

Input / output: Input (CH) 1

USB peripherals (Communication with PC)*1

RS-232C (Printer / PC)

Memory number: 999

Interval memory

Input ID

Display: Display Custom LCD

Ambient temperature: 0 ℃ ~ 45 ℃

Power: AC adapter 100 ~ 240 V 50 / 60 Hz

Demensions: 170 (W) × 174 (D) × 73 (H) mm (Excluding electrode stand and AC adapter)

Power consumption: Approx. 0.7 VA

Mass of main unit: Approx .500

Accessories Included

1).Electrode stand

2) conductivity electrode (3552-10D)

3) 84 uS, 1413 uS, 12.88 mS & 111.9 mS (503-S) conductivity buffers (250 ml)

Manual
