Measurement Range: 0-50mm
Accuracy: ≤1.5um
Minimum: 0.5μm、1μm(Switchable)
Measurement Speed: Maximum 5000mm/s
Force: 1.0-1.5N
External Output: Data Interface、USB
Display: 8 Bit Green High Brightness LED Display
Probe: Spherical Probe, Flat Probe, Needle Probe
Unit: mm、inch( Convertible )
Operating Environment: Temperature：0-40°C Humidity：20-80%
Measuring Table: 130mmx130mm Ceramic
Power Adapter: Input：AC100-240V50/60HZ Output：DC5V/1A
Standard Accessories: ceramic Table，Spherical Probe, Flat Probe, Needle Probe
Optional Accessories: Special-shaped Probe, Mobile power supply
Dimension: 200x138x397mm
Weight: 11.6kg
Production Feature:
High Accuracy≤1.5um, High Resolution 0.5um
Height、Depth、Thickness、Flatness Measurement
Steps and Deep Hole Measuring
Reset from Anywhere
Replaceable Probe
8-digit Highlight LED Digital Display Device
Optional mobile power supply
Stable and Hard-Wearing Cast Iron Base
High Accuracy Ceramic Measuring TableProduction Feature:
High Accuracy≤1.5um, High Resolution 0.5um
Height、Depth、Thickness、Flatness Measurement
Steps and Deep Hole Measuring
Reset from Anywhere
Replaceable Probe
8-digit Highlight LED Digital Display Device
Optional mobile power supply
Stable and Hard-Wearing Cast Iron Base
High Accuracy Ceramic Measuring Table
