Loading Force: 2Kgf Manual Probe HP-2K
Indenter: 136°Vickers Diamond Indenter
Measuring Range: HB 85-650HV 80-1599 HRC 20-70HRB 41-100 HRA 61-85.6 HS 34.2-97.3Mpa 255-2180N/mm
Measuring Accuracy: HV±3%HV HRC±1.5HRC HB±3%HB HLD±5HLD
Measuring Direction: Support 360°
Data Storage: To save 1000-groups of measuring data and 20-groups of calibration data
Hardness Scale: HV、HB、HRC, HLD
Data Display: Loading force, Testing-times, Testing result, Average, Maximum、Minimum、Deviation and Conversion scale.
Hardness Indication: LCD display
Operating Environment: Temperature-10℃~50℃ Humidity 30%~80%R.H
Operating Voltage: DC 6V
Instrument Dimensions: 160x80x31mm
Net Weight: Approximate 500g（Without probe）
Manual Probes Features:
● Introduced latest ultrasonic sensor technology
● Obtain accurate hardness value without auxiliary devices
● Support 360° quick measuring
● Excellent human engineering design easy to hold
● Suitable dimension and weight of probe is convenient to control
● Quick and accurate measuring for edge and fixed position of specimen
● Micro indentation, Non- Destructive for specimen
