Max. Load: 30kN / 3000kgf / 6720lbf
Load accuracy: ≤±1%
Load range: 2%-100% of full scale
Load resolution: 1/200000 of full scale
Disp. resolution: 0.01mm
Test speed: 0.05-500mm/min
Tensile space: 650mm|25.6in
Comp. space: 650mm|25.6in
Test width: 400mm
Temperature range: -40°C~350°C
Thermostat specifications: High precision temperature control meter, multilevel PID adjust, interval 1°C, accuracy: 0.5°C
Temperature fluctuation: ±1°C
Temperature gradient: Better than 3°C
Heating up time: Room temperature to 300°C, less than 50 minutes
Uniform temperature zone length: More than 150mm
Datasheet
Application:
Application to the tensile and creep relaxation strength test if the round specimen, rectangular specimen, and tubular product and other products under GB/T4338 (metal material of high temperature tensile test method), HB5195 (The metal high temperature tensile test method) ,GB/T2039 (the tensile creep rupture and test method), HB5150 (metal high temperature tensile durable test method)
