Technical Specifications
Continuity with 200mA: 0.01Ω ÷ 199.9Ω
Continuity with 10/25A (2-wires, 4-wires): 0.001Ω ÷ 19.99Ω
Insulation resistance
- Test voltage: 100, 250, 500, 1000VDC
- Measuring range: 0.01MΩ ÷ 1000MΩ (1000V)
Residual voltage (Ures): 10V ÷ 460V (AC), 10V ÷ 650V (DC)
AC TRMS voltage: 195V ÷ 253V
AC TRMS current on test socket: 0.01A ÷ 16.0A
AC active/apparent power: 0.0W / VA ÷ 5.06kW / kVA
Power factor (CosPhi): 0.01 ÷ 1.00
Leakage current with optional clamp HT96U: 0.1mA ÷ 1000A
Line/Loop impedance (L-L, L-N, L-PE): 0.01Ω ÷ 200Ω
General Specification
Power supply
Mains voltage: 207V÷ 253V, 50 / 60Hz
Max. absorbed current: 16A
Mechanical characteristics
Size (L x W x H): 400 x 300 x 170mm
Weight: 15kg
Mechanical protection: IP40
Memory and output interface
Internal memory: 999 locations
Output interface: USB 2.0
Saving on USB pen drive: yes
Bluetooth interface connection: yes
USB keyboard: optional
USB printer: optional
USB bar code reader: optional
Keyboard for remote control: optional
Control lamps for dielectric tests: optional
General characteristics
Display: TFT, colour 4.3”, touch-screen
Safety: IEC/EN61010-1, IEC/EN61557-1-2-3-4-6-13 -14; EN50191 (Dielectric tests)
Safety checks: IEC/EN60204-1, IEC/EN61439-1 IEC/EN60335-1
Insulation: class I (conductor PE)
Pollution level: 2
Measurement category: CAT II 300V (Power), CAT III 300V (other tests)
Accessories provided
• C2033X 3-terminal cable with Shuko plug
• 2310-IECIV-200-N Test cable, 2m, Black, 0.75mmq, 2 pcs
• 2317-IECIV-200-R Test cable, 2m, Red, 2.5mmq, 2 pcs
• 2310-IECIV-200-B Test cable, 2m, Blue, 0.75mmq
• 2310-IECIV-200-V Test cable, 2m, Green, 0.75mmq
• 5004-IECN Alligator clip, Black, 4 pcs
• 404-IECN Measuring lead 4mm, Black, 3 pcs
• FT3HVPRB1 Set of 2 safety cables for Dielectric tests
• FT3BRSN Carrying bag for accessories
• TOPVIEW2007 Management software + USB cable C2007
• Quick guide
• User manual on CD-ROM
• Calibration certificate ISO9000
Optional accessories
• HT96U AC clamp for leakage current, 1-100-1000A, diameter 54mm
• IMP57 Accessory for measuring Loop impedance with high resolution
• C2009AD Cable with adapter for connection to IMP57
• 1066-IECN Extension cable connector for cables with 4mm banana connector, Black
• 1066-IECR Extension cable connector for cables with 4mm banana connector, Red
• FT3BARCR Bar code reader with USB port
• FT3KBDEN English keyboard with USB port
• FT3REDLP Red lamp with 7m cable + connector
• FT3RMTCT Adapter for remote control with Start/Stop/Save function
• FT3SFTSW Safety contact with 7m cable for Dielectric tests
• FT3HVTIP Black banana-lead cable for Dielectric tests
• FT3R-GLP Red/green lamp with 7 m cable and connector
• FT3BLACKBOX Test box for Fulltest3
• FT3MPT2 USB thermal printer with 32 columns
