DC VOLTAGE : 1.6 ÷ 599.9V; ±(1.0%rdg+3dgt); 600V RMS
AC VOLTAGE (TRMS)1.6 ÷ 599.9V; 40 ~ 200Hz ±(1.0%rdg+3dgt); 200 ~ 400Hz ±(5.0%rdg+3dgt); 600V RMS
AC/DC VOLTAGE : MAX / MIN / AVG/ PEAK MEASUREMENT
MAX/MIN/AVG: 10.0 ÷ 599.9V; ±(5.0%rdg+10dgt); 500ms; 600V RMS
PICCO: 10 ÷ 850V; ±(5.0%rdg+10dgt); 1ms; 600V RMS
AC CURRENT (TRMS) : 0.0 ÷ 399.9A; 40 ~ 200Hz ±(1.0%rdg+3dgt); 200 ~ 400Hz ±(5.0%rdg+3dgt); 600A RMS
AC CURRENT:PEAK MEASUREMENT
MAX/MIN/AVG: 10.0 ÷ 399.9A; ±(5.0%rdg+10dgt); 500ms; 600A RMS
PEAK: 10.0 ÷ 800A; ±(5.0%rdg+10dgt); 15ms; 600A RMS
RESISTANCE: 0.0 ÷ 499.9Ω/ 500 ÷ 999Ω/ 1000 ÷ 1999Ω; ±(1.0%rdg+5dgt); 600V RMS
FREQUENCY (TEST LEADS / CLAMP’S JAWS) : 40 ÷ 399.9Hz; ±(5.0%rdg+1dgt); 600V RMS
ACTIVE POWER, REACTIVE POWER, APPARENT POWER: 0.00 ÷ 99.99/ 100 ÷ 999.9; ±(3.5%rdg+3dgt)
POWER FACTOR: 0.20 ÷ 1.00; ±3°
PHASE ROTATION TEST AND PHASE COINCIDENCE TEST: 50 ÷ 600V; 600V RMS
AUDIBLE CONTINUITY TEST : Continuity; Built-in buzzer sounds when reading is below approx. 40Ω, the buzzer turns off when reading is greater than 40Ω; <1.5VDC
Display: LCD is 4 digits with maximum reading 9999 counts; Backlight function; Automatic polarity indication.
Function: DCV, ACV, ACA, OHM, W, W3, PHASE SEQ, Audible continuity tests.
Measuring rate: 64 samples/period
Indoor use; Altitude up to 2000m
Pollution degree: 2
Insulation: class 2 (double insulation)
Max. diameter conductor size : 30 mm
Power supply: 2 x 1.5V IEC R03 AAA carbon-zinc or alkaline type batteries; AutoPowerOFF function
Dimension: 205 (H) x 64 (W) x 39 (L) mm
Weight: 280 grams with batteries included.
Accessories:
Rubber cap for test lead
ISO9000 calibration certificate
Bag B80
Pair of Leads YAAMK0000HT0
Pair of Leads YAAMK0001HT0
Batteries and user manual
