DC VOLTAGE: 1.6 ÷ 599.9V; ±(1.0%rdg+3dgt); 600V RMS
AC VOLTAGE (TRMS): 1.6 ÷ 599.9V; 40 ~ 200Hz ±(1.0%rdg+3dgt); 200 ~ 400Hz ±(5.0%rdg+3dgt); 600V RMS
AC/DC VOLTAGE : MAX / MIN / AVG/ PEAK MEASUREMENT
MAX/MIN/AVG: 10.0 ÷ 599.9V; ±(5.0%rdg+10dgt); 500ms; 600V RMS
PICCO: 10 ÷ 850V; ±(5.0%rdg+10dgt); 1ms; 600V RMS
AC CURRENT (TRMS): 0.0 ÷ 399.9A; 40 ~ 200Hz ±(1.0%rdg+3dgt); 200 ~ 400Hz ±(5.0%rdg+3dgt); 600A RMS
AC CURRENT:PEAK MEASUREMENT
MAX/MIN/AVG 10.0 ÷ 399.9A; ±(5.0%rdg+10dgt); 500ms; 600A RMS
PEAK 10 ÷ 800A; ±(5.0%rdg+10dgt); 15ms; 600A RMS
RESISTANCE : 0.0 ÷ 499.9Ω/ 500 ÷ 999Ω/ 1000 ÷ 1999Ω; ±(1.0%rdg+5dgt); 600V RMS
FREQUENCY (TEST LEADS / CLAMP’S JAWS): 40 ÷ 399.9Hz; ±(5.0%rdg+1dgt); 600V/A RMS
ACTIVE POWER, REACTIVE POWER, APPARENT POWER : 0.00 ÷ 99.99/ 100 ÷ 999.9; ±(3.5%rdg+3dgt)
POWER FACTOR: 0.20 ÷ 1.00; ±3°
VOLTAGE & CURRENT HARMONICS
1 ÷ 15; ±(10.0%rdg+5dgt)
16 ÷ 25; ±(15.0%rdg+5dgt)
PHASE ROTATION TEST AND PHASE COINCIDENCE TEST: 50 ÷ 600V; 600V RMS
AUDIBLE CONTINUITY TEST
Continuity; Built-in buzzer sounds when reading is below approx. 40Ω,
the buzzer turns off when reading is greater than 40Ω; <1.5VDC
Display: The liquid crystal display (LCD) is 4 digits with maximum reading 9999 counts; Backlight function; Automatic polarity indication.
Function: DCV, ACV, ACA, OHM, W, W3, HV, HA, PHASE SEQ, Audible continuity tests.
Measuring rate: 64 samples/period
Indoor use; Altitude up to 2000m
Pollution degree: 2
Insulation: class 2 (double insulation)
Max. diameter conductor size : 30 mm
Power supply: 2 x 1.5V IEC R03 AAA carbon-zinc or alkaline type batteries; AutoPowerOFF function
Dimension: 205 (H) x 64 (W) x 39 (L) mm
Weight: 280 grams with batteries included.
Accessories:
Rubber cap for test lead
ISO9000 calibration certificate
Bag B80
Pair of Leads YAAMK0000HT0
Pair of Leads YAAMK0001HT0
Batteries and user manual
