DC Voltage (Autorange):
600.0mV/ 6.000V/ 60.00V/ 600.0V/ 1000V; ±(1.0%rdg + 3dgt); 10MΩ; 1000VDC/ACrms
AC Voltage TRMS (Autorange):
6.000V/ 60.00V/ 600.0V/ 1000V; ±(1.0%rdg + 10dgt)(50 ÷ 60Hz)±(3.5%rdg + 5dgt)(61 ÷ 400Hz); 10MΩ; 50 ÷ 400Hz; 1000VDC/ACrms
60.00V/ 600.0V/ 1000V; ±(1.0%rdg + 4dgt)(50 ÷ 60Hz)±(3.5%rdg + 5dgt)(61 ÷ 400Hz); 50 ÷ 400Hz; 1000VDC/ACrms
Resistance and Continuity test (Autorange):
600.0Ω/ 6.000kΩ/ 60.00kΩ/ 600.0kΩ/ 6.000MΩ; ±(1.0%rdg + 5dgt); ≤ 60Ω; 600VDC/ACrms
60.00MΩ; ±(2.0%rdg + 10dgt); ≤ 60Ω; 600VDC/ACrms
DC Current:
60.00A ±(2.2%rdg + 10dgt)/600.0A ±(2.0%rdg + 8dgt); 600AACrms
AC TRMS Current:
60.00A ±(2.2%rdg + 12dgt) / 600.0A ±(2.2%rdg + 8dgt); 50 ÷ 60Hz ; 600Arms
60.00A ±(3.5%rdg + 12dgt)/ 600.0A ±(3.5%rdg + 8dgt) ; 61 ÷ 400Hz; 600Arms
Capacitance (Autorange):
40.00nF; ±(3.5%rdg + 40dgt); 600VACrms
400.0nF/ 4.000µF/ 40.00µF/ 400.0µF; ±(2.5%rdg + 5dgt); 600VACrms
4000µF; ±(5.0%rdg + 5dgt); 600VACrms
Diode test: 0.9mA typical; 2.8VDC
Frequency with test leads (Autorange):
99.99Hz/ 999.9Hz/ 9.999kHz/ 60.00kHz;±(1.0%rdg + 5dgt); > 15Vrms; 600VDC/ACrms
Frequency with jaws (Autorange):
99.99Hz/ 999.9Hz/ 9.999kHz; ±(1.0%rdg + 5dgt); >10Arms (60A) />50Arms (600A); 600AACrms
Duty Cycle (Autorange): 0.5% ÷ 99.0%;> 15Vrms; ±(1.2%rdg + 2dgt)
Temperature with type K probe (Autorange):
-20.0÷400.0°C; ±(2.0%rdg + 3°C); 600VDC/ACrms
400 ÷ 760°C; ±(2.0%rdg + 5°C); 600VDC/ACrms
-4.0 ÷ 752.0°F; ±(2.0%rdg + 6°F); 600VDC/ACrms
752 ÷ 1400°F; ±(2.0%rdg + 9°F) ; 600VDC/ACrms
Size: 215(L) x 74(La) x 43(H)mm
Weight (including battery): 285g
Max conductor size: 30mm
Battery type: 1 battery 9V NEDA 1604 IEC 6F22 JIS 006P.
AutoPowerOff: about 15 minutes of idleness
Display: 4 LCD (max 6000 counts), decimal point, unit symbol indication, bar graph and backlight
Sample rate: 2 times/sec
Conversion mode: TRMS
Accessories:
Carrying bag HT9015
K-TYPE WIRE PROBE TK101
ADAPTER T10
Pair of Lead YAAMK0000HT0
Batteries and user manual
