Specifications:
- Measuring range: Rockwell: 20-88HRA, 20-100HRB, 20-70HRC
- Superficial Rockwell: 70-94HR15N, 42-86HR30N, 20-77HR45N 67-93HR15T, 29-82HR30T, 10-72HR45T
- Test force: Rockwell 588.4, 980.7, 1471N (60, 100, 150kgf)
- Superficial Rockwell 147.1, 294.2, 441.3N (15, 30, 45kgf)
- Measuring scale: HRA, HRB, HRC, HRN, HRT (Scales of F, G are optional)
- Unit of display: 0.1HR
- Moving range of measuring head: 50mm
- Output: built-in RS232 interface
- Max. height of test piece: 300mm
- Depth of throat: 150mm
- Dimensions: 1000 x 600 x 450mm
- Power supply: 220V AC or 110V AC, 50 or 60Hz
- Weight: approx. 125kg
Standard accessories:
- Small flat anvil: 1 pc.
- V-notch anvil: 1 pc.
- Diamond cone penetrator: 1 pc.
- 1/16" steel ball penetrator: 1 pc.
- Rockwell standardized block: 5 pcs.
- Superficial Rockwell standardized block: 4 pcs.
- Printer: 1 pc.
