Hardness Scales:HL, HRC,HRB,HV,HB,HS
Test Precision:HLD:±6 HRC:±1 HB:±4
StandardImpact Device: impact device of Type D
Upper / Lower Limits Setting:(170-960)HLD, (17.9-69.5)HRC, (19-683)HB, (80-1042)HV, (30.6-102.6)HS, (13.5-101.7)HRB
Optional Impact Device:D/ C /DC / D+15 / DL/ G
PC Interface: USB 2.0
Language:Chinese/English
Screen Display:128X64 dot matrix LCD, backlight and adjustablecontrast
Measuring Direction:360°(down,inclined down,level,inclined up and up)
Data Memory :100 readings
MaximumHardness of The Measured Work Piece:940HV(for D,DC,DL,D+15,C impact device)
Measurable Material:Steel and cast steel, alloy tool steel, stainless steel,gray cast iron, nodular cast iron, aluminum casting alloy, copper zinc alloy(brass), copper tin alloy(bronze), fine copper
Power Supply: 1.5V AAA battery ( 3 PCS)
Working time: about 150 hours
Shape Size:159mm*72mm*28mm
Weight:540g
List of components not warranty:
1 the shell
2 the screen display
3 the panel
4 the impact body
5 the support ring
6 the probe cable
7 ink ribbon
8 the battery(the damage caused by faulty operation problem)
