sampling: 80MSPS
bandwidth: 2.5MHz～6MHz
transmit: ±600V_400Hz_125ns
gain: Automatic 0 ~ 96dB, step 1dB
Measurement accuracy: ±0.01mm
sound velocity range: 400～9999 m/s
Effective range: 0.75～1280 mm
Average grade: L、M、H Third gear adjustable
Lifting distance: 5mm(aluminum), 4mm(carbon steel), 3mm(stainless steel)
Measuring range: Measuring carbon steel — 1X:160mm 2X:320mm 3X:640mm 4X:1280mm
Measuring type: Aluminum, copper, iron, carbon steel, cast steel, alloy steel, stainless steel, titanium alloy and other metal materials
Measuring channel: 2* Thin piece, general purpose, bar
Measurement mode : Single echo (I-E), Double Echo (E-E)
Search pattern: Frontier - frontier, crest - crest, crest - frontier
Auxiliary function: Auto freeze, auto gain, auto sleep, A-scan waveform display, Wi-Fi connected phone
Correction function: Gate height adjustment, delay blanking adjustment, manual gain adjustment, sound velocity calibration, high temperature compensation
Communication: RS-485 or USB2.0
Recharger: 5V2A, Standard Type-C interface
Display screen: 1.47 INCH 320× 172 IPS_LCD
Body size: 178.4 mm× 42 mm× 32 mm
Battery life: 3.7V 3400mAh lithium battery for 6 hours
Weight: A metal shell: 358g; B injection shell: 255g; C injection + quick disassembly: 289g
