Display Type: 2.4QVGA(320×240)true color OLED screen,contrast 10000:1
Operating Principle: Adopts single delay probe ultrasonic measuring principle
Measuring Range: 0.2mm to 25.4mm(0.007874" to 1.00")
Measuring Resolution: Selectable 0.001mm, 0.01mm or 0.1mm (selectable 0.0001, 0.001", 0.01")
Units: Inch or Millimeter
Display Mode: Normal, Minimum / Maximum capture, DIFF/RR%, A-Scan, B-Scan
V-Path Correction: Automatic
Update Rate: Selectable 4Hz, 8Hz, 16Hz per second
Material Velocity Range: 500-9999m/s,0.0179-0.3937in/u
Languages: Chinese, English, French, Germany, Japanese
Alarm Settings: Minimum and Maximum alarms. Dynamic waveform color change on alarm
Power Requirements: 2 AA size batteries
Operating Time: Greater than 35 hours
Instrument Shut-off: Selectable ALWAYS ON or AUTO OFF after 5, 10, 20 minutes of inactivity
Operating Temperature: -10°C to +50°C (+10°F to +120°F); -20°C for special requirements
Size: 153mm × 76mm ×37mm(H ×W ×D)
Weight: 280g including batteries
Standard Configuration
THICKNESS GAUGE: 1
PROBE: 1
COUPLANT BOTTLE: 1
CARRYING CASE: 1
OPERATING MANUAL: 1
USB CABLE: 1
SOFTWARE CD: 1
