High voltage output: 0.5~10kV
Increasing by 500V for each level, a total of 20 levels, capacity: 1500VA
Accuracy: tgδ: ± (reading *1.5% +0.04%)
Cx: ± (reading * 1.5% +5 PF)
Resolution: tgδ: 0.01% Cx: 1pF
Measuring range: 0.01% <tgδ <100%
Internal high pressure: 3PF ～60000PF/10KV 60PF～1µF/0.5KV
External high pressure: 3PF ～1.5µF/10KV 60PF～30µF/0.5KV
Power supply: AC 220V ± 10% 50/60 ± 1Hz
Measuring method:
Working frequency: 50(50Hz measuring), 60(60Hz measuring)
Different frequency: 50D(45Hz/55Hz measure each time)
60D (55Hz/65Hz measure each time)
Automatic frequency conversion
Harmonic adaptation: ≤ 3%
Application condition: -15℃－50℃
Relative humidity <80%
Dimension: 460 (L) × 345 (W) × 345 (H)
Weight: 35 kg
