DC resistance test
Current gear: 10A
Measuring range: 500µΩ ～ 200mΩ
Current gear: 5A
Measuring range: 10mΩ ～ 1Ω
Current gear: 1A
Measuring range: 100mΩ ～ 20Ω
Current gear: 100mA
Measuring range: 10Ω ～200Ω
Current gear: 10mA
Measuring range: 50Ω ～2kΩ
Current gear: 1mA
Measuring range: 500Ω ～50kΩ
Technical index
Accuracy: 士(Reading X 0.2%+2 words)
Maximum resolution: 0.1µΩ
Conditions of use and appearance
Working power supply: Built in lithium battery or external charger, charger input 100 ～240VAC, 50HZ/60HZ
Charging voltage: 16.8V
Charging current: ≤3A
Charging time: About 4 hr
Use time: More than 8 hr
Host weight: 1.6 kg (Test line is not included)
Dimension: 246mm(L)X 156mm(W) X62mm(H)
Use of temperature: -10℃～50℃
Relative humidity: ≤90%，No dew
