Safety Standard
IEC 61010-1 CAT.IV 600V
IEC 61326 EMC specification: test, control and electrical equipment for testing
IEC60529 IP64 （Outer closed state）
AC Power：220V±10%， 50 HZ ，20 VA
Battery：16.8V Lithium ion rechargeable battery
Battery Life：5000V@100M， 6 hour
Size（L x W x H：26cm x 20cm x 16cm
Weight：3kg
Test voltage accuracy: the nominal value 100% to 110%
Voltage measurement accuracy：5%+3V
Current test range：10mA
Current measure precision：5%+0.2nA
Short-circuit current： 5mA
Capacitance test range：20uF
Capacitance testing accuracy：15%+0.03uF
Capacitor discharge rate： from 5000V to 10V，0.5S/µF
Insulation resistance testing range and accuracy: T: 23±5ºC，RH: 45 – 75%
