Gender: Jack (Socket)
Polarity: Standard
Impedance: 50 Ohms
Isolation: Non-Isolated
RF Series: SMB
Body Style: Bulkhead
Cable Type: EZ-86-TP-M17, MULTIFLEX-86, SUCOFORM-86
Body Finish: Gold
Orientation: Straight
Unit Weight: 1.800 g
Contact Type: Socket (Female)
REACH - SVHC: Details
Body Material: Brass
Mounting Style: Cable Mount / Free Hanging
Contact Plating: Gold
Contact Material: Brass
Maximum Frequency: 4 GHz
Termination Style: Solder
Contact Termination: Solder
Maximum Operating Temperature: + 165 C
Minimum Operating Temperature: - 65 C
