Internal dimension: (W*D*H)1000*1000*1000mm
External dimension: (W*D*H)1300*1100*1700mm
Oscillating tube: Radius 400mm
Oscillating angle:
IPX3: spray ±60° from vertical line to each side, total 120°
IPX4: spray ±180° from vertical line to each side, total 360°
Oscillating speed:
IPX3: 2*120° for 4s
IPX4: 2*360° for 12s
Spray nozzle: Diameter: 0.4mm, removable
Distance between two nozzles: 50mm
Turntable diameter: 500mm
Turntable rotation speed: 1-3 cycles/min
Water flow of each nozzle: 0.07 L/min +5%
Test duration: 1~999h999min, adjustable
Pressure gauge: 80-150Kpa
Distance from nozzle to specimen surface: 200mm
Chamber material: Stainless steel, with observation window
Safety protection device: Short circuit protection, grounding protection, water shortage protection, audible and visual alarm
Power supply source: 1-phase, 220V±10%, 50Hz
