1. 3-phase constant current source charging, charging current: 3A/1A step, 0.6A/0.2A step
2. Max. Terminal voltage: 24V
3. Max. Range of transient resistance: 100Ω
4. Measuring range of transient resistance: 1A step: 0.4Ω-20Ω; 0.2A step: 10Ω-100Ω
5. Time length of waveform recording: 300ms
6. Sampling rate: 30k
7. Time resolution: 0.1ms
8. Resistance resolution: 0.1Ω
9. Accuracy:
Transient resistance: ±5% of the reading±0.1Ω
Transient time: ±0.5% of the reading±0.2ms
10. Working condition: Temperature -10~40℃, Humidity<85% RH
