1. Power frequency Discharge Voltage Test
Output voltage: AC 0.00-30.0kV
Resolution: 0.1kV
Measurement accuracy: ±1.5%±2digits.
Test interval time: ≥15s
Function: Automatic calculation of the three average values after the test is completed.
Print: Test result can be printed.
2. DC 1mA reference voltage test
Rated output: DC 0-30kV, current 0-1000μA
Measurement range: Current 0-1000μA, voltage 0-30.0kV
Resolution: Current 1μA, voltage 0.1kV
Accuracy: ±1.5%±1digit.
Function: With function of residual voltage automatic discharge.
Print: Test result can be printed.
3. Other parameters
Power supply: 220V±10%
Ambient temperature: -10℃~50℃
Relative humidity: ≤80%
Altitude: <1000M
Size & Weight: Main unit: 380*280*210mm, 5.8kg
Testing transformer: 255*150*255mm, 8.7kg
