PERFORMANCE
Range: 0 – 10,000 cP
Measurement Time: 1 second
Accuracy: 1% of reading or +/- 0.1cP
Repeatability: 0.3% of reading or +/- 0.05cP
OUTPUTS / INPUTS
Analog Outputs: 2 × 4-20mA configurable, representing viscosity, ref. viscosity, or temperature
Digital: RS485 ModBus Data Link to host system or PC running ViscoLink
Power: 24v DC @ 80mA
TEMPERATURE
Integral Thermometer: Integrated temperature measurement
Standard Range: -50 °C to 100 °C
PRESSURE
Standard Range: 100 Bar
PIPE CONNECTION
Standard fitting: All common pipe fittings available
Mounting: 4x M5 mounting holes
ELECTRICAL CONNECTION
Cable Length: As required – not affected by cable length up to 1000m
Cable Type: Any standard instrument cable
CONSTRUCTION
5.5mm Bore: Smooth uninterrupted bore - no welds or crevices
MATERIALS
Enclosure: Anodised 6082 aluminium
Fitting: As Required
Tube Material: Alloy C276 (EN 2.4819)
WEIGHT: 1.8kg
SOFTWARE: ViscoLink data viewing and logging PC software
