Continuous Power (kVA/kW): 20/16
Standby Power (kVA/kW): 22/17.6
Power Factor: 0.8
Frequency (Hz): 50
Voltage (V): 230/400
Current (A): 30.39
ATS Connection Port: Yes
Fuel Tank Capacity (L): 78
Fuel Consumption (L/h): 6
Running Time at 70% Load (h): 14
Noise Level at 7m (dBA): 72
Total Weight (kg): 819
Dimensions (L×W×H) (mm): 2008×900×1130
Engine
Model: 4H2.7-G2
Speed (RPM): 1500
Fuel Type: Diesel
Configuration: 4 cylinders, inline
Compression Ratio: 18:1
Cooling System: Water-cooled with fan
Coolant Capacity (L): 8
Lubricating Oil Capacity (L): 6
Lubricating Oil Consumption (L/h): 0.032
Intake Air Flow (m³/min): 2.3
Exhaust Gas Flow (m³/min): 5.7
Exhaust Gas Temperature (°C): 480
Exhaust Back Pressure (KPa): 10
Engine Dimensions (mm): 953×522×728
Engine Weight (kg): 260
Alternator
Model: 184ES
Alternator Power (kVA): 23
Phase: 3-phase
Bearing Type: Single bearing
Power Factor (Cosφ): 0.8
Voltage Regulation: Automatic AVR with AS440
Protection Class: IP23
Insulation Class: Class H
Excitation System: Automatic
