Size: 105mm x 146mm x 70mm
Weight: 345g
Voltage: 5V
Current: 50mA (standby); 500mA (working)
Sensor pixel: 1280 pixels (H) x 800 pixels (V)
Light source: 650nm RED LED
Field of view angle: Horizontal ≥50°, Vertical ≥35°
Sensitivity: Tilt ±65°, Rotate 360°, Deflection ±60°
Motion tolerance: Up to 2m/s
Print contrast: ≥20%
Communication Interface: USB, RS232
Reading accuracy: ≥3.9mil
Code system
One-dimensional (1-D): UPC, EAN, Code 128, Code 39, Code 93, Code 11, Matrix 2 of 5, Codabar, Interleaved 2 of 5, MSI Plessey, GS1 DataBar, China Postal, Korean Postal, etc.
Two-dimensional (2-D): QR Code, MicroQR, PDF417, MicroPDF417, Data Matrix, Maxicode, Aztec, Hanxin, etc.
Typical code: Reading distance
Code 39: 0mm - 60mm
5mil: 0mm - 60mm
100% UPC-A (13mil): 0mm - 200mm
Operating temperature: 0°C ~ 50°C
Storage temperature: -40°C ~ 70°C
Humidity: 0% ~ 95% relative humidity, no condensation
Anti-vibration: Can withstand a 1.5-meter drop test
Ambient light immunity: 100 000 Lux
