Size: 180mm * 95mm * 70mm
Weight: 212g
Voltage and current: 5VDC ±10% @500mA
Sensor pixel: 640 pixels(H) * 480 pixels(V)
Light source: Aiming: 617nm LED, illumination: 6500K LED
Field of view: Horizontal 45°(H) x Vertical 35°(V)
Rotate / Tilt / Deflection: 360°, ±65°, 60°
Battery capacity: 4.2V / 2500mAh
Charging time: 5-6H
Battery life: 1S scan once, can work continuously for 18H
Wireless technology: Bluetooth 4.0
Operating distance: 100 meters (open space)
Print contrast: Minimum 25% reflection difference
Motion tolerance: Up to 25 in. (63.5cm) per second
Interface support: USB, RS232
Support one-dimensional barcode (1-D): UPC, EAN, Code128, Code39, Matrix 2 of 5, Interleaved 2 of 5, Codabar, MSI Plessey, GS1 DataBar, China Postal, Korean Postal, etc.
Support two-dimensional barcode (2-D): PDF417, MicroPDF417, Data Matrix, Maxicode, QR Code, MicroQR, Aztec, Hanxin, etc.
Operating temperature: 0°C to 50°C
Storage temperature: -40°C to 70°C
Humidity: 0% to 95% (no condensation)
Anti-vibration: Designed to withstand 1.5m (5') drops
Ambient light immunity: 1000,000 lux
Decoding Range:
5mil (Code39): 50mm - 110mm
13mil (100% UPC-A): 30mm - 3000mm
1D Minimal Resolution: 4mil
