Type of light: red light
Housing: threaded type
Function principle: Through-beam sensor
Operating voltage [V]: 10...30 DC
Current consumption [mA]: 20
Protection class: III
Reverse polarity protection: yes
Wave length [nm]: 645
Transmitter / receiver: transmitter
Range [m]: < 8
Range adjustable: no
Max. light spot diameter [mm]: 600
Ambient temperature [°C]: -25...60
Protection: IP 67; (in conjunction with a corresponding connector)
Weight [g]: 14.3
Dimensions [mm]: M18 x 1 / L = 44
Materials: housing: ABS
Lens material: PMMA
Display: operation 1 x LED, green
Items supplied: lock nuts: 2 x
Connection: Connector: 1 x M12; coding: A
