Type of light: red light
Housing: threaded type
Function principle: Through-beam sensor
Operating voltage [V]: 10...36 DC
Current consumption [mA]: 15
Protection class: II
Reverse polarity protection: yes
Wave length [nm]: 624
Transmitter / receiver: transmitter
Range [m]: < 20
Range adjustable: no
Max. light spot diameter [mm]: 800
Ambient temperature [°C]: -25...60
Protection: IP 67
Weight [g]: 49.1
Dimensions [mm]: M18 x 1 / L = 60
Materials: housing: stainless steel (1.4404 / 316L)
Lens material: PMMA
Display: operation 1 x LED, green
Items supplied: lock nuts: 2 x
Connection: Connector: 1 x M12; coding: A
