Voltage: 60V
Current: 50A
Power: 600W
Min operating voltage: 2V@50A
CC mode
Range: 0~5A/ 0~50A
Setting Resolution: 0.1mA/ 1mA
Setting Accuracy (23±5℃): Low range:0.1%+0.1%F.S.,/ High range:0.1%+0.15%F.S
CV mode
Range: 0~6V/ 0~60V
Setting Resolution: 0.1mV/ 1mV
Setting Accuracy: (23±5℃) 0.05%+0.1%F.S.
CP mode
Range: 0~600W
Setting Resolution: 10mW
Setting Accuracy (23±5℃): 0.5%+1%F.S
CR mode
Range: 0.03~120Ω/ 0.5~1200Ω
Setting Resolution: 16 bits
Setting Accuracy (23±5℃): 0.35%+2.7mS/ 0.35%+0.27mS
Slew Rate
Current: 0.8~50A/ms/ 50~2500A/ms
Voltage: 0.5~25V/ms/ 25~250V/ms
Power: 0.8~50A/ms/ 50~2500A/ms
Resistance: 0.8~50A/ms/ 50~2500A/ms
Voltage Measurement
Range: 0~6V/ 0~60V
Readback Accuracy (23±5℃): 0.05%+0.05%F.S.
Current Measurement
Range: 0~5A / 0~50A
Readback Accuracy (23±5℃):0.1%+0.1%F.S.
Interface: LAN/RS232
AC Input: Single phase, 220V AC±10%, frequency 47Hz~63Hz
Sampling Frequency: 25Hz
Communication Response Time: ≤10ms
Operating Environment: Altitude: <2000m, relative humidity: 5%~90%RH(non-condensing), atmospheric pressure: 80~110kPa
Temperature: Operating temperature: 0℃~40℃, storage temperature: -20℃~60℃
Net weight: Approx. 13kg
Dimension: 2U, 88.0(H)*482.0(W)with handle*507.0(D)mm
