Process type: batch
Operating principle: cutting/impact
Motor rating input: 160 W
Motor rating output: 100 W
Speed max: 28000 rpm
Circumferential speed max.: 53 m/s
Useable volume max.: 80 ml
Feed hardness max.: 6 Mohs
Feed grain size max.: 10 mm
Material beater/cutter: stainless steel 1.4034
Material milling chamber: stainless steel 1.4301
Power-ON time: 1 min
Power-OFF time: 10 min
Mill feed can be cooled in milling chamber with dry iceyes
Mill feed can be cooled in milling chamber with liquid nitrogenyes
Dimensions (W x H x D): 85 x 240 x 85 mm
Weight: 1.5 kg
Permissible ambient temperature: 5 - 40 °C
Permissible relative humidity80 %
Protection class according to DIN EN 60529: IP 43
Voltage: 220 - 230 / 100 - 115 V
Frequency: 50/60 Hz
Power input: 160 W
