Stirring quantity max. per stirring position (H2O): 25 l
Motor rating input: 60 W
Motor rating output: 46 W
Motor principle: Brushless DC
Speed display: LED
Speed min.: 30 rpm
Speed min.: 0/30 rpm
Speed max.: 1000 rpm
Viscosity max.: 30000 mPas
Output max. at stirring shaft: 42 W
Permissible ON time: 100 %
Torque max. at stirring shaft: 40 Ncm
Torque max. at stirring shaft at 60 1/min (overload): 40 Ncm
Torque max. at stirring shaft at 100 1/min: 40 Ncm
Torque max. at stirring shaft at 1.000 1/min: 40 Ncm
torque I max.: 40 Ncm
Speed range I (50 Hz): 30 - 1000 rpm
Speed range I (60 Hz): 30 - 1000 rpm
Speed control: Turning knob
Setting accuracy speed: 1 ±rpm
Deviation of speed measurement n > 300rpm: 1 ±%
Deviation of speed measurement n < 300rpm: 3 ±rpm
Stirring element fastening: chuck
Connection for ext. temperature sensor: PT1000
Temperature display: yes
Chuck range diameter: 0.5 - 8 mm
Hollow shaft, inner diameter: 8.5 mm
Hollow shaft (push-through - when stopped): yes
Fastening on stand: extension arm
Extension arm diameter: 13 mm
Extension arm length: 160 mm
Timer display: yes
Speed control: electronic
Nominal torque: 0.2 Nm
Torque measurement: trend
deviation of torque measurement I: 4 ±Ncm
Timer: yes
Timer display: LCD
Time setting range: 0 - 6000 min
Temperature measuring range: -10 - 350 °C
Temperature measurement resolution: 0.1 K
Accuracy of temperature measurement: ±0.5 + tolerance PT1000 (DIN IEC 751 Class A) K
Limit deviation temperature sensor: ≤ ± (0.15 + 0.002xITI) K
housing material: alu-cast coating / thermoplastic polymer
communication distance (depend onbuilding) max.150 m
Dimensions (W x H x D): 70 x 193 x 154 mm
Weight: 1.72 kg
Permissible ambient temperature: 5 - 40 °C
Permissible relative humidity: 80 %
Protection class according to DIN EN 60529: IP 54
USB interface: yes
Voltage: 100 - 240 V
Frequency: 50/60 Hz
Power input: 69 W
DC Voltage: 24 V=
Current consumption: 2900 mA
