Pump rate max. (50/60Hz): 1.32 m³/h
Pump rate max. (50/60Hz): 22 l/min
Final pressure without gas ballast: 2 mbar
Suction levels: 4
Cylinder: 4
Connection diameter suction side: 8 mm
Connection diameter pressure side: 8 mm
Input pressure: 2 - 1030 mbar
Two-point control: yes
Analog speed vacuum control: yes
Speed control: Turning knob
Speed range: 285 - 1200 rpm
Display: LED
Noise at low. pressure: 54 dB(A)
Material in contact with mediumAl2O3, PTFE, FPM, PPS
housing material: alu-cast coating / thermoplastic polymer
Mode automatic: yes
Mode manual: yes
Mode pump %: yes
Mode program: yes
Dimensions (W x H x D): 150 x 375 x 370 mm
Weight: 11.5 kg
Permissible ambient temperature: 5 - 40 °C
Permissible relative humidity: 80 %
Protection class according to DIN EN 60529: IP 20
RS 232 interface: yes
USB interface: yes
Voltage: 100 - 240 V
Frequency: 50/60 Hz
Power input: 130 W
Power input standby: 3 W
