Pump rate max. (50/60Hz): 1.32 m³/h
Pump rate max. (50/60Hz): 22 l/min
Final pressure without gas ballast: 2 mbar
Suction levels: 4
Cylinder: 4
Connection diameter suction side: 8 mm
Connection diameter pressure side: 8 mm
Input pressure: 2 - 1030 mbar
Boiling point detection: yes
Solvent library: yes
Analog speed vacuum control: yes
Speed control: Turning knob
Speed range: 285 - 1200 rpm
Display: TFT
Pressure unit / scale: mbar, hPa, mmHg, Torr
Vacuum sensor: yes
Vacuum sensor type: ceramic Al2O3
Pressure max. for pressure sensor: 1.2 bar
Measurement range (absolute): 1 - 1030 mbar
Control range: 1 - 1030 mbar
Resolution pressure: 1 mbar
Measurement uncertainty: 1 mbar
Venting valve: yes
Condensate trap: yes
Emission condenser: yes
Timer: yes
Noise at low. pressure: 54 dB(A)
Material in contact with mediumAl2O3, PTFE, FPM, PPS
housing material: alu-cast coating / thermoplastic polymer
Mode automatic: yes
Mode manual: yes
Mode pump %: yes
Mode program: yes
Dimensions (W x H x D): 270 x 435 x 500 mm
Weight: 19 kg
Permissible ambient temperature: 5 - 40 °C
Permissible relative humidity: 80 %
Protection class according to DIN EN 60529: IP 20
RS 232 interface: yes
USB interface: yes
Voltage: 100 - 240 V
Frequency: 50/60 Hz
Power input: 140 W
Power input standby: 1.5 W
