Minimum detectable leak rate: < 5 x 10-12 mbar l/s
Maximum inlet pressure: 0.4 mbar
Operational mode: wide range without crossover(12 decades)
Helium pumping speed at inlet: 2.5 l/s
Ion source: 2 longlife Iridium filaments, Yttrium-oxide coated
Start-up time: < 3 minutes
Inlet port / Fore-vacuum port: DN 25 KF
Power supply: 85 - 265 V, 50/60 Hz
Control inputs: 8 x PLC compatible (max. 35 V)
Status / Valve control / Trigger outputs: 9 / 11 / 3 x relay contacts (max. 60 V AC / 25 V DC / 1 A)
Chart recorder output lin/log: 2 x 0-10 V, programmable
Recommended fore-vacuum pump: 2.5 - 16 m3/h, wet or dry
Dimensions (width x depth x height): 535 x 350 x 339 mm (21 x 13.8 x 13.4 in)
Weight: 30 kg (66 lbs)
