Core: ARM Cortex M3
Width: 15.5 mm
Height: 1.95 mm
Length: 12 mm
Antenna: Trace
Protocol: BLE, Bluetooth 5.0
Data Rate: 3 Mb/s
Frequency: 2.44 GHz
Shielding: Shielded
Dimensions: 12 mm x 15.5 mm x 1.95 mm
Memory Size: 512 kB
Sensitivity: - 93.5 dBm
Unit Weight: 3 g
Output Power: 9 dBm
Interface Type: I2C, SPI, UART
Mounting Style: SMD/SMT
Frequency Range: 2.402 GHz to 2.48 GHz
Moisture Sensitive: Yes
Modulation Technique: 4-DQPSK, 8-DPSK, GFSK
Receiver Sensitivity: - 93.5 dBm
Supply Voltage - Max: 3.6 V
Supply Voltage - Min: 2.3 V
Antenna Connector Type: SMA
Operating Supply Voltage: 2.3 V to 3.6 V
Supply Current Receiving: 26.4 mA
Supply Current Transmitting: 52.5 mA
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 30 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
