Fall Time: 11.7 ns
Rise Time: 8.6 ns
Technology: SiC
Channel Mode: Enhancement
Configuration: Single
Mounting Style: Through Hole
Transistor Type: 1 N-Channel
Qg - Gate Charge: 124 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Vgs - Gate-Source Voltage: - 10 V, + 25 V
Typical Turn-On Delay Time: 9.5 ns
Typical Turn-Off Delay Time: 21 ns
Id - Continuous Drain Current: 129 A
Maximum Operating Temperature: + 175 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 38 S
Rds On - Drain-Source Resistance: 12 mOhms
Vds - Drain-Source Breakdown Voltage: 1.2 kV
Vgs th - Gate-Source Threshold Voltage: 5.1 V
