Fall Time: 61 ns
Rise Time: 4.9 ns
Technology: Si
Unit Weight: 340 mg
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Single
Mounting Style: Through Hole
Transistor Type: 1 N-Channel
Qg - Gate Charge: 4.7 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 22.7 W
Vgs - Gate-Source Voltage: - 16 V, + 16 V
Typical Turn-On Delay Time: 12 ns
Typical Turn-Off Delay Time: 63 ns
Id - Continuous Drain Current: 4 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 40 C
Rds On - Drain-Source Resistance: 1.15 Ohms
Vds - Drain-Source Breakdown Voltage: 700 V
Vgs th - Gate-Source Threshold Voltage: 2.5 V
