Imaging and optics
Detector type: unrefrigerated vanadium oxide/7.5µm~14µm
Infrared resolution: 256x192@12µm
Thermal sensitivity/NETD: ≤45mK
Infrared frame rate: 25Hz/9Hz
Focal length: 3.2mm
Field of view: 56°x48°
Spatial resolution (IFOV): 3.75mrad
Minimum object distance: 0.3m
Distance to spot size (D:S): 266:1
Focusing mode: focus-free
Digital zoom: 1.1x~8x
Laser ranging: ≤8m
Measurement and analysis
Measurement range: support auto-switching: -20°C~150°C, 100°C~550°C
Measurement accuracy: ±2°C or ±2%, whichever is greater
Analyzed target: spot x 2 (include center spot), area x 3
Tracking/alarm: full-screen maximum/minimum temperature tracking; the maximum or minimum temperature tracking of analyzed target; full-screen temperature threshold alarm (image and flash)
Temperature measuring parameter: emissivity, reflected temperature, target distance
Other: intelligently calculate the area
Image display
Display screen: 3.5" LCD
Digital camera: 5MP
Image mode: IR, VIS, MIF, PIP
Image adjustment: automatic, semi-automatic, manual
Color palettes: white hot, black hot, iron red, hot iron, rainbow, arctic
Function
Recording function: photo
Cloud service: available
Other: customized physical button x 2
Storage and transmission
Storage media: local storage (16GB)
Image storage: JPG with temperature information
External interface: TYPE-C
WIFI: can be connected to the mobile terminal for image transmission
Power system
Battery type: rechargeable lithium-ion battery, working time ≥4 hours
Charging mode: TYPE-C charging; PC/portable charger, capable of charging while using
Charging time: 90% of full charge in 2.5 hours
Environmental parameter
Operating temperature: -10°C~50°C
Storage temperature: -40°C~70°C
Protection: IP54, 1m drop test
Certification: CE, FCC, ROHS
Physical parameter
Hardware: illuminator, laser (indicator, ranging)
Dimension: 138x89x35mm
Weight: 296g
