Magnification: 40X~400X
Eyepiece (wide field): 10X (view field: ϕ22mm)
Objective (plan achromatic): 4X; 10X; 20X; 40X
Working distance: 17.8mm; 10mm; 5.8mm; 2.9mm
Numerical aperture: 0.10; 0.25; 0.40; 0.60
Stage:
-Double layer
-Size: 300x268mm
-Travel: 250x200mm
Kohler illumination: 6V/20W halogen lamp, brightness is adjustable; built-in green, blue, yellow, and frosted glasses
Pupil distance: 48~75mm
Diopter adjustment: ±5 diopter (two eyepieces)
Power supply: 220V, 50/60Hz
Dimension: 647x268x376mm
Weight: 12kg
Standard delivery:
-Main unit: 1pc
-Camera connector: 1pc
-Anti- dust cover: 1pc
Optional accessory:
-Bright field objective:
2.5X plan achromatic objective (focus distance: 11.7mm)
5X plan achromatic objective (focus distance: 15.5mm)
50X plan achromatic objective (focus distance: 0.32mm)
100X plan achromatic objective (focus distance: 2mm)
-Polarizer and analyzer
-Digital camera
-Camera adpater 0.5X
