Direct access to our certified experts
Objective(infinite plan achromatic) / Numerical aperture / Working distance
5X / 0.15 / 16mm
10X / 0.30 / 9mm
20X / 0.45 / 3mm
50X / 0.80 / 3mm
Eyepiece: Large field 10X (view field: Ø23mm)
Objective (infinite plan achromatic): Bright field objectives
Optical magnification: 50X - 500X (up to 1000X with optional 100X objective)
Stage: X-Y double layer
Size: 200 × 150mm
Travel: 78 × 50mm
Condenser: Pre-centered condenser with diaphragm indicator scale markings NA 0.1 ~ 1.1
Diopter adjustment: ±8 diopter
Observation tube: 30° hinged trinocular observation tube, pupil distance adjustment range 45 - 78mm
Power supply: Power adapter
Dimension (W × D × H): 391 × 220 × 513mm
Weight: 18kg
