SPECIFICATION
Measuring range: 0-3000μm
Resolution
0.1μm (range<100μm)
1μm (100μm≤ range<1000μm)
0.01mm (1mm≤ range<3mm)
Accuracy: ±(2μm+3%L); L is measuring thickness in um
Measure interval: 0.5s
Calibration mode: zero calibration
Display: LCD
Working temperature: -20~50°C
Unit: μm/mil
Language: Chinese, English, Russian, Turkish, Ukrainian
Power supply: 2x1.5V AAA batteries
Dimension: 100×60×24mm
Weight: 80g
STANDARD DELIVERY
Main unit: 1 pc
Fe zero calibration plate: 1 pc
NFe zero calibration plate: 1 pc
Standard foil (100μm): 1 pc
1.5V AAA battery: 2 pcs
■ Suitable for both magnetic and non-magnetic metal substrates
■Can measure the thickness of non-magnetic coating and non-metallic
coating on magnetic metal substrate
Substrate: iron, steel, magnetic stainless steel
Coating: zinc, aluminum, copper, chrome, tin, plastic, powder, paint (not for nickel)
■ Can measure the thickness of non-conductive coating on non-magnetic metal substrate
Substrate: copper, aluminum, zinc, non-magnetic stainless steel
Coating: plastic, powder, paint, anodizing (not for chrome and zinc plating)
■ Can quickly detect the paint thickness of iron and aluminum body of car, three colors of backlight indication, can identify non-metal shell and iron powder putty layer
■ Can connect to mobile APP, measure and generate test reports in real time, and save or share the report
■ Built-in multiple languages
■ Store 9 measuring records
■ Small and portable, easy for operation
Datasheet
