Features:
Image mode: IR, visible image, PIP and MIF
Storage: SD card (16GB)
Image format: JPG with temp info
Output: USB
Power: Rechargeable Li-ion battery, working time ≥4h
Color palette: 6 modes
Specifications:
IR resolution: 160x120
NETD: ≤50mk
Focus length: 5mm/F1.2
Angle of view: 30°x23°
Spatial resolution: 3.30mrad
Focus adjustment: fixed
Detector type: unrefrigerated vanadium oxide/8~14μm
Pixel size: 17μm
Visible camera: resolution 640x480, automatic focus
Display: 3.5" hightlight LCD screen, 320x240
Digital zoom: x2, x4
Temperature range: -20°C~350°C
Accuracy: ±2°C or ±2% (of maximize range)
Emissivity: 0.01-1.00 (adjustable)
Operating temperature: -10°C~50°C
Operating humidity: -10%~95%RH
Vibration: 10HZ~150HZ~10HZ 0.15mm (IEC60068-2-6)
Impact: 30g (IEC 60068-2-27)
Weight: 740g
Dimension: 258x98x90mm
Standard delivery: Main unit, power supply adapter, USB cable, 16G SD card
