Specification
Display screen: 7" TFT LCD touch screen display
Display mode: graphic display, digital display
Number of channels:1
Range:
10 µm
20 µm
50 µm
100 µm
Resolution:0.1μm
Unit:mm
Air supply:dry and clean, 0.4-0.7MPa
Data interface:RS232/USB*
Operation temperature:-10-55°C
Power supply:220V, 50/60Hz
Dimension (LxWxH):240×230×230mm
Weight:5.6kg
*RS4885 port, l/O port, Ethernet communication port can be customized according to customer requirements
Standard Delivery
Main unit:1 pc
- Data sforage function, 2 million groups dafa can be stored
- Can store 10 groups measuring programs, and the program can be switched quickly
- Insert USB flash disk to output storage data, updata program
- Data can be shared or networked via TCP/IP (customized)
- With data stafistics and analysis funotions, can display graphs and Xbar-R control charts
