Specification
Analogue bandwidth: 100MHz
Channel: 2
Maximum real-time sampling rate: 1GSa/s (non-interleaved mode)
Rise time: ≤3.5ns
Memory depth: 64kpts
Waveform capture rate: 5000wfms/s
Vertical scale (V/div): 1mV/div~20V/div
Time base scale (s/div): 2ns/dlv-50s/div
Storage method: setup, wave, bitmap
Trigger type: edge, pulse, alternate, slope, video
Trigger mode: auto, normal, single
Trigger coupling: DC, AC, HF, LF, noise
Cursor measurement: time, voltage, tracking
Parameter measurement: automatic measurement of multiple waveform parameters
Mathematical operation: : , -, x, +, FFT, filter
Digital filter: low pass, high pass, band pass, band stop
Setting: internal: 20 groups. USB: 200 groups
Waveform: internal: 20 groups. USB: 200 groups
Recorded frame: 1000 frames of screen data
Interface: USB Host, USB Device, Pass/Fail
Maximum input voltage: 300Vrms, the transient over voltage is 1000 Vpk.
Probe compensator output: voltage: about 3Vp-p
frequency: 10Hz, 100Hz, 1kHz, 10kHz
Power supply: AC 100V-240V, 50-60Hz
Dimension (LxWxH): 306mmx138mmx124mm
Weight: 2.5kg
Standard Delivery
Main unit: 1pc
Passive probe: 2pc
USB cable: 1pc
■ Analogue bandwidth: 100MHz
■ Memory depth: 64kpts
■ Sampling rate per channel: 1GSa/s(non-interleaved mode) Waveform capture rate: 5,000wfms/s
■ Automatic measurement of multiple waveform parameters Multiple frequency standard square waves can be output:10Hz, 100Hz, 1kHz, 10kHz
■ Sampling mode: real-time sampling and equivalent sampling
■Lissajous method: measuring the phase of a waveform
