Detection channel: channel1 (X1-Y1), channel2 (X2-Y2), mixing channel
Detection frequency: 2
Transmission frequency: 50Hz-10MHz
Driving voltage: 8 adjustable steps
Phrase adjustment: 360° (1° step)
Gain adjustment: 0-90dB (step 0.1dB)
Sampling frequency: 40MHz, 12-bit data acquisition
Digital filtering: high pass: 1Hz-1950Hz, low pass: 3Hz-2000Hz
Alarm mode: amplitude and phase alarm
Alarm box: alarm frame modes: off, amplitude-phase, half-amplitude phase, square box
Probe type: bridge
Display: time base, impedance plane
Auxiliary measurements: automatic/manual measurement of amplitude and phase
Balance mode: digital balance
Display mode: dot, line, fade mode
Interface: Q9 interface, USB HOST, Mini HDMI
Environmental temperature: -10-50°C
Relative humidity: 20~95%RH
Power supply: rechargeable lithium battery, working time 6-8h
Dimension: 251x171x52mm
Weight: 1.5kg
STANDARD DELIVERY
Main unit: 1pc
Pen probes 50K-500KHz: 1pc
Pen probes 500K-3MHz: 1pc
Right angle probes 50K-500KHz: 1pc
Right angle probes 500K-3MHz: 1pc
Aluminum alloy flat test block: 1pc
Stainless steel plate test block: 1pc
Hexagon bar wrench: 1pc
Probe connecting cable: 1pc
Mainframe backpack: 1pc
USB disk: 1pc
Power adapter: 1pc
■ Real-time impedance plane and time base sweep display modes available
■ Easy to operate menu interface, with universal knob operation is more convenient and fast
■ Analyzes the signal waveform of the entire detection process, automatically measuring phase and amplitude.
■ With amplitude and phase alarms and settable boundaries
■ 5.7" industrial-grade TFT display, can work in outdoor and direct sunlight environment
■ 500 sets of data, 500 sets of parameters, or 40 minutes of video storage
■ Applicable to all kinds of metal materials and parts, such as weld cracks, copper pipe, seamless steel pipe, stainless steel pipe, folding, scars, pits, cracks, delamination and other defects, has a high sensitivity
