Measuring range (XxYxZ): 200x100x200mm
Stage size:404x228mm
Glass stage size: 260x160mm
Resolution of X/Y/Z axis: 1µm
Accuracy of X/Y/Z axis: ≤(3+L/200)µm
Repeatability of X/Y/Z axis: 2µm
Objective: 0.7X - 4.5X (zoom)
View field (diagonal length): 1.0 - 6.6mm
Working distance: 92mm
Magnification: 37.2X - 236.0X (on 21.5" monitor)
Camera: 1/2" color CCD, 1.3M pixel
Illumination: surface and contour with adjustable LED
Max. height of workpiece: 200mm
Max. weight of workpiece: 20kg
Operation system: Window 10/11
Drive method: manual
Power supply: 220V, 50Hz
Dimension (LxWxH): 556x540x860mm
Weight: 180kg
